What sets the PEPS detection system apart from all other genetic tests is its ability to simultaneously detect multiple DNAs and RNAs directly from the clinical sample in one test in a rapid, low-cost, and portable format.

A fully automated PEPS detection system to rapidly and accurately assess multiple disease-related DNAs and RNAs from patient samples all in 40 minutes or less is particularly useful to combat acute infectious diseases.

Delivery of such time-critical information at point of care will enable physicians to provide timely patient care to achieve improved patient outcomes and reduce the spread of the disease at a lower cost.

The low-cost and point-of-care nature of the PEPS system will particularly benefit small and medium-sized hospitals, which account for 80% of the market but cannot afford expensive automated PCR systems.

For more information about the PEPS system can be found here.

There are 3 million Clostridium difficile (CD) infection (CDI) cases in the US each year, accounting for 20-30% of hospital-associated diarrhea, causing 14,000 deaths and costing more than $3B to treat annually.

Enzyme immunoassay (EIA) for C. difficile toxins is inexpensive but the sensitivity is only 60%. Automated genetic tests are sensitive but expensive. As a result, current recommendations call for a two-step testing procedure combining toxins EIA and nucleic acid amplication testing (NAAT) such as PCR and loop-mediated isothermal amplification (LAMP) to lower the cost. However, the two-step testing procedure takes time which can delay timely treatment of the disease.

Although NAATs detect the DNA of one of the toxin genes, either tcdA or tcdB, there is no telling if the toxin is expressed or how much the toxin is expressed. Since toxins are what cause the disease, it would be ideal if the genetic test can detect not only the DNA of the toxin gene but also its mRNA to help assess the toxin expression activity.

Furthermore, the severity of CDI is associated with the presence of a binary toxins gene. It would be important to not only detect the toxin genes and their mRNAs but also the binary toxin gene and its mRNA to help diagnose the disease but also assess the severity of the disease, which will help the clinicians to make better treatment decisions and achieve improved patient outcomes.

Although most CDIs involve both toxin A and toxin B, some CDIs involve only toxin B and no CDIs involve only toxin A. Lenima offers a 4-plex CDI test to detect the DNA of toxin B gene, tcdB, and its mRNA transcription level as well as the DNA of the binary toxin B gene, cdtB, and its mRNA transcription level directly from patient stool in 40 minutes or less.

Note for current NAATs to detect two genes and two mRNAs it would require four tests. In addition, the mRNA tests would require additional reverse transcription steps.

For more information about the CDI test can be found here.

The PEPS blood cancer test is a multiplexed test that detects a cancer-specific marker, Tn antigen and its antibody produced by the immune response in the blood that can be used to detect the presence of cancer in high risk individuals for further cancer imaging testing.

Tn antigen is a cancer-specific marker for epithelial tissues. Recent studies from Drs. Wan Y. Shih and We-Heng Shih's lab has further shown that Tn antigen as a marker can differentiate cancer from normal tissues and benign tumors with 95% sensitivity and 90% specificity in tissue microarrays. This indicates that Tn antigen can be a cancer-specific marker for a blood molecular test for early detection of cancer in high risk individuals. The challenge is that circulating Tn antigen so far has been undetectable by the current test methods due to the fact that Tn antigen in the circulation is rapidly cleared by the liver. The  unprecedented sensitivity exhibited by PEPS makes PEPS ideal to detect the otherwise undetectable Tn antigen and anti-Tn antibody in the patient’s blood.

The PEPS blood cancer test is inexpensive and minimally invasive while highly sensitive and specific and can be easily administered at the point of care to prescreen high risk individuals for further cancer imaging testing. Below are some of the example applications of the blood PEPS Tn test.

Breast cancer (BC) is the leading cause of cancer for women. Thanks to the improvement in BC screening and treatment of localized BC there are now 3.1 million BC survivors in the US. 1 in 5 of these BC survivors will experience recurrence. BC survivors are followed up regularly for BC recurrence using standard diagnostic, mammography. However, after the surgery and radiation therapy, the remaining breast is highly scarred, making mammography and MRI ineffective in detecting BC recurrence. In addition, there are no recommended serum markers or standard imaging to detect distant recurrences.

Preliminary results of the PEPS blood cancer test exhibited 93% sensitivity and >90% specificity in detecting BC against non-cancer in 24 patient sera (14 BC of stages 0-3 and grades 1-3 and 10 non-cancer sera including 2 with benign conditions such as polyp and endometrial hyperplasia). It detected Tn in the sera of BC patients at concentrations as low as 30 pg/ml and with tumor sizes as small as 0.3 cm. With such encouraging preliminary results and that BBC, like normal tissues, does not express Tn it is expected the PEPS blood cancer test will detect BC with >90% sensitivity and >90% specificity against BBC and other non-cancer conditions for early BC recurrence detection applications. Based on $20/kit, this represents a $60 MM/year market for the US alone.

In addition, more and more young women under 40 are at high risks of breast cancer. These are young women with a family history of breast cancer or young women who are BRCA1 and BRCA2 positive. Mammography is not effective for young women. These women are often tested with MRI to detect breast cancer. However, MRI is expensive and has many false positives. Given that there are 3.1 million breast cancer survivors, the number of women with a family history of breast cancer and women who are BRCA1 and BRCA2 positive can be easily more than 3.1 million, representing a >$60 MM/year market for the US alone.

In the US, over 228,190 people will be diagnosed with lung cancer and over 159,480 people will die of lung cancer in 2014, accounting for 27% of all cancer deaths. The 5-year survival rate for lung cancer is less than 16%. The statistics of lung cancer is very alarming because lung cancer is asymptomatic and there is no screening test for lung cancer.

Low-dose CT scan (LDCT scan) can detect early-stage lung cancer. However, 1 in 4 LDCT scans of high-risk individuals (smokers and former smokers with more than 30 pack-years) will be positive while biopsy of every 20 positive LDCT scans yields only 1 positive diagnosis of lung cancer, i.e., the false positive rate is an alarming 95%. It would be desirable to have an inexpensive, minimally-invasive blood molecular test that can be given at point of care as a prescreening test to identify high risk individuals for further cancer imaging testing to reduce the rate of false positives and unnecessary biopsies.

85% of lung cancers are epithelial cancers. The PEPS blood cancer test is inexpensive and minimally invasive while highly sensitive and specific to detect cancer and it can be easily administered at the point of care to prescreen high risk individuals for further cancer imaging testing. The PEPS blood cancer test will help detect lung cancers at earlier stages while minimizing unnecessary biopsies and save lives. Based on $20/kit, the market for lung cancer screening for the US alone is $350 MM/year.

Cancer is a genetic disease driven by genetic changes (mutations) and/or epigenetic changes (hypermethylation). Cancers with different genetic/epigenetic changes respond to therapies differently. For this reason, it is often necessary to assess a cancer’s genetic makeup before embarking on the treatment. In addition, a cancer’s genetic makeup may evolve as a result of the cancer therapy. Therefore, it is also necessary to assess changes in a cancer’s genetic makeup during the course of the treatment. Current cancer genetic testing rely on gene sequencing which requires high-quality solid-tumor samples with more than 50% of cells being cancer cells. The difficulty with gene sequencing is that once the primary tumor is removed by the initial treatment, there is no longer solid tumor sample available.

The alternative is to assess cancer genetic makeup using circulating DNA in the blood or other biological fluids with polymerase chain reaction (PCR). To detect a genetic change, say, mutation against the normal form of the gene (wild type) from the normal cells, PCR rely on the fact that the melting temperature for the binding of the mutant to the probe DNA (pDNA) is different from that for the binding of the wild type to the pDNA. For point mutations, this melting temperature difference is only a few degrees. This, coupled with the fact that mutant is often outnumbered by the wild type by a factor of 1000 in circulating DNA, makes circulating gene mutation difficult.

Our previous work has shown that flow can enhance the specificity of mutation detection because flow can generate an impingement force which can act to discriminate against the weaker binding of the wild type to the pDNA on the PEPS surface. By conducting mutation detection in a flow with optimal temperature and flow control PEPS has demonstrated capable of K-ras point mutation detection in situ with 60 copies/ml analytical sensitivity in a background of 1000-fold wild type, indicating the sensitivity and specificity of PEPS in circulating mutation detection. In addition, PEPS does not require expensive fluorescent label and can be easily multiplexed, and is low-cost.
